리튬 전지 공장 전문 맞춤형 포도당 측정기 배터리 UFX 301645 3.7V 180mAh 리튬 폴리머 배터리

$1.10
In stock
SKU
UFX 301645 3.7V 180mAh

가격 : US $ 1.2-1.5 / 암페어
Min. 주문 : 2,000 암페어
주문 하시려면 저희에게 문의하십시오!

    브랜드 이름: BZ
    모델 번호: 301645
    유형: 리튬 폴리머
    공칭 전압: 3.7V
    크기: 3*16*47mm
    공칭 용량: 180mAh
    제품 이름: 301645 리튬 이온 배터리
    보증: 1년
    무게: 3g
    주기 생활: 500배
    용량: 180mAh
    전압: 3.7V
    적용 분야: 혈당 측정기 배터리
    증명서: RoHS/MSDS
    지불: Paypal.TT.Escrow.Western Union
    최대 충전 전류: 1C



리튬 이온 배터리


공장 사용자 정의 3.7V 180mAh 배터리

혈당 측정기 용 3.7V 180mAh 배터리

301645 3.7V 180mAh 리튬 폴리머 배터리


Product Parameters

No.

Item

General Parameter

Remark

1

Rated Capacity

Typical

185mAh

Standard discharge(0.2C C5A) after Standard charge

Minimum

180mAh

2

Nominal Voltage

3.7V

Mean Operation Voltage

3

Voltage at end of

3.0V

Discharge Cut-off Voltage

Discharge

4

Charging Voltage

4.2±0.03V



5

Internal Impedance

≤280mΩ

Internal resistance measured at AC 1KHZ after 50% charge

The measure must uses the new batteries that within one week after shipment and cycles no more than 5 times

6

Standard charge

Constant Current 0.2C5A

Charge time : Approx 6h

Constant Voltage 4.2V

0.01 C5A cut-off

7

Standard discharge

Constant current 0.2 C5A



end voltage 3.0V

8

Fast charge

Constant Current 0.5C5A

Charge time : Approx 2.5h

Constant Voltage 4.2V

0.01 C5A cut-off

9

Fast discharge

Constant current 0.5C5A



end voltage 3.0V



10

Maximum Continuous Charge Current

1 C5A



11

Maximum Continuous Discharge Current

1C5A



12

Operation Temperature Range

Charge: 0~45

60±25%R.H.

Bare Cell

Discharge: -20~60



13

Storage Temperature Range

Less than 1 year: -20~25

60±25%R.H.

less than 3 months: -20~40℃

at the shipment state

14

Pack  Dimension

High: max47mm

Width: max16mm
Thickness: max3mm

Initial  Dimension
